Detective+ Multigas Monitor
Designed for group protection, area monitoring and providing a virtual
fenceline, Detective+ is a rugged, interconnectable, multigas temporary
area monitor. Building on Crowcon's
experience in pioneering this category of detector, Detective+ has
earned a reputation for reliability and versatility in demanding
environments stretching from offshore platforms to the sands of the
Middle East.
Overview
Rugged and robust, Detective+ features either fixed or folding legs
and a protective frame that allows stacking for easier storage.
Available with an optional internal pump for sampling versatility,
alarms are announced with an extremely loud sounder, while multiple
beacons ensure 360 degree visibility.
Detective+ may now also be equipped with infra-red (IR) sensors, providing either CO2 detection,
or allowing higher levels of flammable gas monitoring. IR sensors also
provide immunity to the poisoning effects which standard flammable gas
sensors can suffer from. This extends sensor life and further increases
measurement confidence in tough applications such as water treatment
plants and certain chemical or hydrocarbon processing facilities.
Versatile and user friendly
- Infrared sensors available - allows sampling of highly flammable gas levels and carbon dioxide. They are also unaffected by poisoning
- Built-in pump option - provides fast response and extra sensor protection, and sampling versatility
- Clear display - provides clear information and allows indentification of gas hazard
Rugged, tripod design
- Raised sensor apertures - prevents water ingress
- Folding or fixed leg options - allows stacking for easier storage and transportation
- IP65 specifications - provides excellent sensor protection
Loud and clear alarms
- 25 Detective+ units may be linked together, up to 100m from adjacent units - all linked Detective+ units indicate an alarm sensed by any one unit
- Units sending an alarm flash faster - provides effective warning of gas hazards
- Audible and visual confidence blip
- Vivid red LED clusters for visual alarm
- Multiple beacons - ensures 3600 visibility
|
Sensor Baffle plate
- C01325
- Provides additional protection for sensor apertures in extreme conditions, for example by reducing splash back and sand ingress.
|
Detective Plus Water Trap
- C011033
- Use to help reduce particulate and water ingress when sampling via a tube.
|
Computer lead assembly
- E07394
- Enables the Detective Plus to be connected to a PC for data download,
calibration and configuration.
- Crowcon Portables PC (C01832) is also
required, as may an RS232-USB adaptor (C02097) if the PC does not have
an RS232 port.
|
USB to RS232 adaptor
- C02097
- Enables RS232 lead to connect to USB ports.
|
|
|
|
|
|
|
